RCD, 40A, 1+N pole, CKN6-40/1N/C/003-A-DE 241593

Lokaler Index:
ARB122MOEL
Katalognummer:
241593
EAN-Code:
4015082415938
Hersteller: EATON
Number of poles: 2
Differential current [mA]: thirty
Rated current [A]: 40
Preis:
64,08 €
gross / stk.
(inklusive MwSt 23%)
Lieferung in 3h
Nicht auf Lager
Abholung in 1 Stunde
Menge stk.
(mehrere:
1
)
Zur Angebotsanfrage hinzufügen
Drucken

Produktbeschreibung

Overcurrent circuit breakers with CKN6 residual current module. 6 kA, 1+N-pole, 250 A current surge proof, sinusoidal and rectified pulse current sensitive, type A

Technische Daten

  • Number of poles
    2
  • Rated current [A]
    40
  • Differential current [mA]
    thirty
  • Trigger type
    AND

Weitere technische Daten

  • Number of poles (total)
    2
  • Rated voltage
    230 V
  • Rated impulse withstand voltage Uimp
    4 kV
  • Rated fault current
    0.03 A
  • Current limiting class
    3
  • Rated short-circuit breaking capacity according to IEC 60947-2
    0 kA
  • Surge current capacity
    0.25 kA
  • Frequency
    50 Hz
  • Concurrently switching neutral conductor
    Yes
  • Over voltage category
    3
  • Ambient temperature during operating
    -25 ... 40 °C
  • Built-in depth
    69.5 mm
  • Anti-nuisance tripping version
    No
  • Connectable conductor cross section solid-core
    1 ... 25 mm²
  • Number of protected poles
    1
  • Rated insulation voltage Ui
    250 V
  • Rated current
    40 A
  • Leakage current type
    A
  • Rated short-circuit breaking capacity according to EN 61009
    6 kA
  • Rated short-circuit breaking capacity Icn according to EN 61009-1
    6 kA
  • Voltage type
    AC
  • Release characteristic
    C
  • With interlocking device
    No
  • Pollution degree
    2
  • Width in number of modular spacings
    2
  • Do instalacji podtynkowych
    No
  • Degree of protection (IP)
    IP20
  • Connectable conductor cross section multi-wired
    1 ... 25 mm²

Hersteller-Details

  • Hersteller
    EATON Electric Sp. z o.o.
  • Adresse
    80-299 Gdańsk ul. Galaktyczna 30
  • Steueridentifikationsnummer
    5841022327
