Motor protection switch 3A, 3-pole, Z-MS-0, 40/3 248404
Lokaler Index:
ASN509MOEL
Katalognummer:
248404
EAN-Code:
4015082484040
Preis:
229,28 zł
gross / stk.
(inklusive MwSt 23%)
Lieferung in 3h
Abholung in 1 Stunde
Menge stk.
(mehrere:
1
)
Zur Angebotsanfrage hinzufügen
Zur Zwischenablage hinzufügen
Drucken
Fragen Sie nach dem Produkt
Produktbeschreibung
Motor circuit breakers Z-MS
• Rated conditional short-circuit current Iq = 10kA
• Rated conditional short-circuit current Iq = 10kA
Technische Daten
-
Number of poles3
-
Overload release setting range [A]0.25-0.40
Weitere technische Daten
-
Overload release current setting0.25 ... 0.4 A
-
With thermal overload protectionYes
-
Switch off techniqueMagnetic
-
Rated permanent current Iu0.4 A
-
Rated operation power at AC-3, 400 V0.09 kW
-
Type of control elementRocker lever
-
With integrated auxiliary switchNo
-
Number of poles3
-
Degree of protection (IP)IP20
-
Width54 mm
-
Adjustment range undelayed short-circuit release3.1 ... 4.8 A
-
Phase failure sensitiveNo
-
Rated operating voltage400 ... 400 V
-
Rated operation power at AC-3, 230 V0 kW
-
Type of electrical connection of main circuitScrew connection
-
Device constructionComplete device in housing
-
With integrated under voltage releaseNo
-
Rated short-circuit breaking capacity lcu at 400 V, AC10 kA
-
Height75 mm
-
Depth80 mm
Hersteller-Details
-
HerstellerEaton Electric Sp. z o.o.
-
Adresse80-299 Gdańsk Galaktyczna 30 Polska
-
E-Mail
Großpackungen
| Eine Art Paket | Skrzynia | Karton | Skrzynia | Karton |
| Menge | 1 stk. | 40 stk. | 1 stk. | 40 stk. |
| Gewicht (kg) | 0,366 | 14,640 | 0,366 | 14,640 |
| Volumen (m3) | 0,000 | 0,016 | 0,000 | 0,016 |
| Breite (m) | 0,086 | 0,385 | 0,086 | 0,385 |
| Länge (m) | 0,055 | 0,180 | 0,055 | 0,180 |
| Tiefe (m) | 0,075 | 0,230 | 0,075 | 0,230 |
