Motor protection switch 2A, 2-pole, Z-MS-2.5/2 248395
local index:
ASN515MOEL
Catalog No:
248395
EAN code:
4015082483951
Price:
38,44 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Motor circuit breakers Z-MS
• Rated conditional short-circuit current Iq = 10kA
• Rated conditional short-circuit current Iq = 10kA
Technical data
-
Number of poles2
-
Overload release setting range [A]1.60-2.50
Other technical data
-
Overload release current setting1.6 ... 2.5 A
-
With thermal overload protectionYes
-
Switch off techniqueMagnetic
-
Rated permanent current Iu2.5 A
-
Rated operation power at AC-3, 400 V0.75 kW
-
Type of control elementRocker lever
-
With integrated auxiliary switchNo
-
Number of poles2
-
Degree of protection (IP)IP20
-
Width36 mm
-
Adjustment range undelayed short-circuit release25 ... 33 A
-
Phase failure sensitiveNo
-
Rated operating voltage400 ... 400 V
-
Rated operation power at AC-3, 230 V0 kW
-
Type of electrical connection of main circuitScrew connection
-
Device constructionComplete device in housing
-
With integrated under voltage releaseNo
-
Rated short-circuit breaking capacity lcu at 400 V, AC10 kA
-
Height75 mm
-
Depth80 mm
Manufacturer details
-
ManufacturerEATON ELECTRIC SP. Z O.O.
-
Address80-299 UL. GALAKTYCZNA 30
-
E-mail
-
Tax identification number5841022327
Bulk packaging
| A kind of package | Skrzynia | Karton | |
| Quantity | 1 pcs. | 1 pcs. | 60 pcs. |
| Weight (kg) | 0,244 | 0,244 | 14,640 |
| Volume (m3) | 0,000 | 0,000 | 0,016 |
| Width (m) | 0,036 | 0,086 | 0,385 |
| Length (m) | 0,080 | 0,037 | 0,180 |
| Depth (m) | 0,075 | 0,075 | 0,230 |
