Electrical apparatus
Motor circuit breakers
Motor circuit breakers for rail mounting
Motor circuit breaker 3A, 3-pole, Z-MS-40/3 248414
local index:
ASN503MOEL
Catalog No:
248414
EAN code:
4015082484149
Click on the photo to enlarge
Manufacturer:
EATON
Number of poles:
3
Overload release setting range [A]:
25.0-40.0
See full description
Price:
68,46 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to cart
Add to clipboard
Print
Ask about the product
Product description
Technical data
Bulk packaging
Product description
Motor circuit breakers Z-MS.
• Rated conditional short-circuit current Iq = 10kA
Technical data
Number of poles
3
Overload release setting range [A]
25.0-40.0
Other technical data
Overload release current setting
25 ... 40 A
With thermal overload protection
Yes
Switch off technique
Magnetic
Rated permanent current Iu
40 A
Rated operation power at AC-3, 400 V
18.5 kW
Type of control element
Rocker lever
With integrated auxiliary switch
No
Number of poles
3
Degree of protection (IP)
IP20
Width
54 mm
Adjustment range undelayed short-circuit release
400 ... 520 A
Phase failure sensitive
No
Rated operating voltage
400 ... 400 V
Rated operation power at AC-3, 230 V
0 kW
Type of electrical connection of main circuit
Screw connection
Device construction
Complete device in housing
With integrated under voltage release
No
Rated short-circuit breaking capacity lcu at 400 V, AC
10 kA
Height
75 mm
Depth
80 mm
Bulk packaging
A kind of package
Skrzynia
Karton
Quantity
1 pcs.
40 pcs.
Weight (kg)
0,366
14,640
Volume (m3)
0,000
0,016
Width (m)
0,086
0,385
Length (m)
0,055
0,180
Depth (m)
0,075
0,230
