Choose your wholesaler

FAZ-B6/2-DC Circuit breaker 10kA, In=6A, character B, 2-pole. FAZ DC series 176078

Name: FAZ-B6/2-DC Circuit breaker 10kA, In=6A, character B, 2-pole. FAZ DC series
Brand: EATON
SKU: ABB116MOEL
Price: 220.83 PLN
Availability: BackOrder

local index:

ABB116MOEL

Catalog number:

176078

EAN code:

4015081712748

FAZ-B6/2-DC Circuit breaker 10kA, In=6A, character B, 2-pole. FAZ DC series

Click on the photo to enlarge

Manufacturer: EATON

Price:

220,83 zł

gross / pcs.

(including VAT 23%)

2 weeks

On request

Quantity pcs.

(multiplicity:

)

Add to inquiry

Add to clipboard

Ask about the product

Technical data Manufacturer details Bulk packaging Files to download

Technical data

Other technical data

Built-in depth

70.5 mm
Number of poles (total)

2
Rated current

6 A
Rated insulation voltage Ui

440 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

0 kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

0 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

10 kA
Current limiting class

3
Concurrently switching neutral conductor

No
Pollution degree

2
Width in number of modular spacings

2
Explosion-proof

No

Release characteristic

B
Number of protected poles

2
Rated voltage

500 V
Rated impulse withstand voltage Uimp

4 kV
Voltage type

DC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

10 kA
Power loss

2.3 W
Flush-mounted installation

No
Over voltage category

3
Additional equipment possible

Yes
Degree of protection (IP)

IP20

Manufacturer details

Manufacturer

Eaton Electric Sp. z o.o.
Address

80-299 Gdańsk Galaktyczna 30 Polska
E-mail

wsparcietech@eaton.com

Bulk packaging

A kind of package	Skrzynia	Karton	Karton
Quantity	1 pcs.	1 pcs.	60 pcs.
Weight (kg)	0,219	0,243	14,155
Volume (m3)	0,000	0,000	0,016
Width (m)	0,038	0,037	0,180
Length (m)	0,082	0,086	0,385
Depth (m)	0,078	0,075	0,230
