Circuit breaker, CLS6-B13/3-DP 270407

Name: Circuit breaker, CLS6-B13/3-DP
Brand: EATON
SKU: ABB203MOEL
Price: 44.64 PLN
Availability: InStock

Lokaler Index:

ABB203MOEL

Katalognummer:

270407

EAN-Code:

4015082704070

Klicken Sie auf das Foto, um es zu vergrößern

Hersteller: EATON

Number of poles: 3

Rated current [A]: 13

Siehe vollständige Beschreibung

Auslauf

Stan produktu: Towar jest fabrycznie nowy, nieuszkodzony. Może nosić ślady długiego magazynowania.

Opakowanie: Towar może zostać dostarczony w opakowaniu zastępczym lub w lekko uszkodzonym oryginalnym opakowaniu.

Dostępność: Tylko w ilości dostępnej na magazynie.

Auslauf

Preis:

44,64 zł

gross / stk.

(inklusive MwSt 23%)

Niedrigster Preis ab 30 Tage vor Ermäßigung: 151,13 zł gross -106,49 zł

Herstellerpreis: 137,39 zł gross

Zugänglich 4 stk.

Menge stk.

(mehrere:

1

)

Zur Angebotsanfrage hinzufügen

Zur Zwischenablage hinzufügen

Drucken

Fragen Sie nach dem Produkt

Produktbeschreibung Technische Daten Hersteller-Details

Produktbeschreibung

• Circuit breakers for industrial applications
• Rated current up to 63 A
• Characteristics B, C, D
• Rated short-circuit breaking capacity 6 kA according to IEC/EN 60898-1
• Optical contact setting status indicator (red/green)
• Rich additional equipment
• Rated voltage 230/400 V, 50 Hz
• Rated current up to 125 A
• Characteristics B, C, D
• Rated short-circuit breaking capacity up to 25 kA according to EN 60947-2
• Optical contact setting status indicator (red/green)
• Rich accessories

Technische Daten

Number of poles

3

Rated current [A]

13

Weitere technische Daten

Release characteristic

B
Number of protected poles

3
Rated voltage

400 V
Rated impulse withstand voltage Uimp

4 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

0 kA
Frequency

50 ... 60 Hz
Do instalacji podtynkowych

No
Over voltage category

3
Additional equipment possible

Yes
Built-in depth

70.5 mm
Ambient temperature during operating

-25 ... 55 °C
Connectable conductor cross section solid-core

1 ... 25 mm²

Number of poles (total)

3
Rated current

13 A
Rated insulation voltage Ui

440 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

0 kA
Voltage type

AC
Current limiting class

3
Concurrently switching neutral conductor

No
Pollution degree

2
Width in number of modular spacings

3
Degree of protection (IP)

IP20
Connectable conductor cross section multi-wired

1 ... 25 mm²
