Circuit breaker 1-pole, CLS6-C10-DP 270350

Name: Circuit breaker 1-pole, CLS6-C10-DP
Brand: EATON
SKU: ABC209MOEL
Price: 20.87 PLN
Availability: BackOrder

Indice locale:

ABC209MOEL

Numero di catalogo:

270350

Codice EAN:

4015082703509

Clicca sulla foto per ingrandire

Produttore: EATON

Number of poles: 1

Rated current [A]: 10

Vedi la descrizione completa

Prezzo:

20,87 zł

gross / pezzi

(inclusa IVA 23%)

Esaurito

Aggiungi alla richiesta di preventivo

Stampa

Chiedi informazioni sul prodotto

Descrizione del prodotto Dati tecnici Dettagli del produttore

Descrizione del prodotto

CLS6 circuit breaker. Characteristic C, rated short-circuit breaking capacity 6 kA.

Release characteristic

C
Number of protected poles

1
Rated voltage

230 V
Rated impulse withstand voltage Uimp

4 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

0 kA
Frequency

50 ... 60 Hz
Do instalacji podtynkowych

No
Over voltage category

3
Additional equipment possible

Yes
Built-in depth

70.5 mm
Ambient temperature during operating

-25 ... 55 °C
Connectable conductor cross section solid-core

1 ... 25 mm²

Number of poles (total)

1
Rated current

10 A
Rated insulation voltage Ui

440 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

0 kA
Voltage type

AC
Current limiting class

3
Concurrently switching neutral conductor

No
Pollution degree

2
Width in number of modular spacings

1
Degree of protection (IP)

IP20
Connectable conductor cross section multi-wired

1 ... 25 mm²
