Basic direct D porcelain. E27 DII 3P 25A LE27K-3
local index:
ABO106HAGE
Catalog No:
LE27K-3
EAN code:
3250614132087
Price:
31,71 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Basic direct D porcelain. E27 DII 3P 25A
Technical data
-
Length [mm]120
-
Rated current [A]25
-
Fuse link sizeDII
-
Rated switching voltage [V]550/0/550
-
Rated short-circuit breaking capacity Icn [A]25
-
Number of poles3
-
Width [mm]46
-
Height [mm]47
-
Fuse link rated current [A]2/4/6/10/16/20/25
-
PKWIU27.12.40.0
Other technical data
-
Number of poles3
-
MaterialPorcelain
-
Version with coverYes
-
Rated voltage500 V
-
Construction sizeDII
-
ModelFitted screw
-
Mounting methodDIN rail
-
Rated current25 A
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta | |
| Quantity | 1 pcs. | 4 pcs. | 36 pcs. | 864 pcs. |
| Weight (kg) | 0,363 | 1,545 | 14,750 | 377,000 |
| Width (m) | 0,080 | 0,155 | 0,290 | 0,800 |
| Length (m) | 0,065 | 0,075 | 0,250 | 1,250 |
| Depth (m) | 0,122 | 0,270 | 0,480 | 1,200 |
