AZ series 4-pole circuit breaker, AZ-4-C20 211772

local index:
ABC005MOEL
Catalog No:
211772
EAN code:
4015082117726
Manufacturer: EATON
Number of poles: 4
Rated current [A]: 20
Price:
331,39 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
3
)
Add to clipboard
Print

Product description

AZ overcurrent circuit breakers (direct current). Characteristic C, rated short-circuit breaking capacity 25 kA.

Technical data

  • Number of poles
    4
  • Rated current [A]
    20

Other technical data

  • Release characteristic
    C
  • Number of protected poles
    4
  • Rated voltage
    400 V
  • Rated impulse withstand voltage Uimp
    4 kV
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
    0 kA
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
    25 kA
  • Frequency
    50 ... 60 Hz
  • Concurrently switching neutral conductor
    Yes
  • Pollution degree
    2
  • Width in number of modular spacings
    6
  • Degree of protection (IP)
    IP20
  • Connectable conductor cross section multi-wired
    2.5 ... 50 mm²
  • Number of poles (total)
    4
  • Rated current
    20 A
  • Rated insulation voltage Ui
    440 V
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
    0 kA
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
    25 kA
  • Voltage type
    AC
  • Current limiting class
    3
  • Over voltage category
    3
  • Additional equipment possible
    Yes
  • Built-in depth
    75 mm
  • Ambient temperature during operating
    -25 ... 55 °C
  • Connectable conductor cross section solid-core
    2.5 ... 50 mm²

Bulk packaging

A kind of package Skrzynia Karton Karton
Quantity 1 pcs. 3 pcs. 12 pcs.
Weight (kg) 0,933 2,800 11,367
Volume (m3) 0,001 0,002 0,012
Width (m) 0,110 0,330 0,192
Length (m) 0,092 0,091 0,335
Depth (m) 0,077 0,080 0,180
