3-pole miniature circuit breakers, CLS6-B6/3-DP 270405

Name: 3-pole miniature circuit breakers, CLS6-B6/3-DP
Brand: EATON
SKU: ABB216MOEL
Price: 19.79 PLN
Availability: InStock

Indeks lokalny:

ABB216MOEL

Nr katalogowy:

270405

Kod EAN:

4015082704056

3-pole miniature circuit breakers, CLS6-B6/3-DP

Kliknij zdjęcie, aby powiększyć

Producent: EATON

Number of poles: 3

Rated current [A]: 6

Type: CLS6-B6/3

Zobacz cały opis

Cena:

19,79 €

gross / szt.

(w tym VAT 23%)

Dostępne 1 szt.

Ilość szt.

(wielokrotność:

)

Dodaj do schowka

Drukuj

Zapytaj o produkt

Opis produktu Dane techniczne Dane producenta

Opis produktu

• Circuit breakers for industrial applications
• Rated current up to 63 A
• Characteristics B, C, D
• Rated short-circuit breaking capacity 6 kA according to IEC/EN 60898-1
• Optical contact setting status indicator (red/green)
• Rich additional equipment
• Rated voltage 230/400 V, 50 Hz
• Rated current up to 125 A
• Characteristics B, C, D
• Rated short-circuit breaking capacity up to 25 kA according to EN 60947-2
• Optical contact setting status indicator (red/green)
• Rich accessories

Dane techniczne

Number of poles

3
Type

CLS6-B6/3

Rated current [A]

6

Pozostałe dane techniczne

Release characteristic

B
Number of protected poles

3
Rated voltage

400 V
Rated impulse withstand voltage Uimp

4 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

0 kA
Frequency

50 ... 60 Hz
Do instalacji podtynkowych

No
Over voltage category

3
Additional equipment possible

Yes
Built-in depth

70.5 mm
Ambient temperature during operating

-25 ... 55 °C
Connectable conductor cross section solid-core

1 ... 25 mm²

Number of poles (total)

3
Rated current

6 A
Rated insulation voltage Ui

440 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

0 kA
Voltage type

AC
Current limiting class

3
Concurrently switching neutral conductor

No
Pollution degree

2
Width in number of modular spacings

3
Degree of protection (IP)

IP20
Connectable conductor cross section multi-wired

1 ... 25 mm²
