3-pole miniature circuit breakers, CLS6-B10/3-DP 270406

local index:
ABB249MOEL
Catalog No:
270406
EAN code:
4015082704063
Manufacturer: EATON
Number of poles: 3
Rated current [A]: 10
Type: CLS6-B10/3
Price:
18,45 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Accessible 1 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
It is not possible to add more of this product to the cart. Goods at a promotional price can only be purchased in the quantity available in stock.
Print

Product description

• Circuit breakers for industrial applications
• Rated current up to 63 A
• Characteristics B, C, D
• Rated short-circuit breaking capacity 6 kA according to IEC/EN 60898-1
• Optical contact setting status indicator (red/green)
• Rich additional equipment
• Rated voltage 230/400 V, 50 Hz
• Rated current up to 125 A
• Characteristics B, C, D
• Rated short-circuit breaking capacity up to 25 kA according to EN 60947-2
• Optical contact setting status indicator (red/green)
• Rich accessories

Technical data

  • Number of poles
    3
  • Type
    CLS6-B10/3
  • Rated current [A]
    10
  • PKWIU
    27.12.10.0

Other technical data

  • Release characteristic
    B
  • Number of protected poles
    3
  • Rated voltage
    400 V
  • Rated impulse withstand voltage Uimp
    4 kV
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
    6 kA
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
    0 kA
  • Frequency
    50 ... 60 Hz
  • Do instalacji podtynkowych
    no
  • Over voltage category
    3
  • Additional equipment possible
    yes
  • Built-in depth
    70.5 mm
  • Ambient temperature during operating
    -25 ... 55 °C
  • Connectable conductor cross section solid-core
    1 ... 25 mm²
  • Number of poles (total)
    3
  • Rated current
    10 A
  • Rated insulation voltage Ui
    440 V
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
    6 kA
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
    0 kA
  • Voltage type
    AC
  • Current limiting class
    3
  • Concurrently switching neutral conductor
    no
  • Pollution degree
    2
  • Width in number of modular spacings
    3
  • Degree of protection (IP)
    IP20
  • Connectable conductor cross section multi-wired
    1 ... 25 mm²
