ZJU-50/BK (20 PCS) CONNECTOR R34RR-07010000743

Name: ZJU-50/BK (20 PCS) CONNECTOR
Brand: ERGOM
SKU: TES043ERGO
Price: 11.41 PLN
Availability: BackOrder

Index local:

TES043ERGO

Numéro de catalogue:

R34RR-07010000743

Cliquer sur la photo pour l'agrandir

Producteur: ERGOM

Prix:

11,41 zł

gross / pcs.

(y compris la TVA 23%)

jusqu'à 4 semaines

Sur commande

Quantité pcs.

(plusieurs:

)

Ajouter à la demande de devis

Ajouter au presse-papiers

Imprimer

Renseignez-vous sur le produit

Données techniques Détails du fabricant Emballage en vrac

Données techniques

Connectable conductor cross section fine-strand without cable end sleeve

10 ... 35 mm²
Connectable conductor cross section solid-core

10 ... 50 mm²
Rated voltage

1000 V
Type of electrical connection 2

Screw connection
Number of poles

1
Mounting method

DIN rail (top hat rail) 35 mm
Operating temperature

-25 ... 55 °C
Width/grid dimension

15.2 mm
Closing plate required

No
With integrated feed-through flange

No

Connectable conductor cross section fine-strand with cable end sleeve

10 ... 25 mm²
Rated current In

150 A
Type of electrical connection 1

Screw connection
Connection position

Sideways
Number of clamp positions per pole

2
Material insulation body

Thermoplastic
Inflammability class of insulation material according to with UL94

V0
Explosion-tested version 'Ex e'

No
Colour

Black
