Threaded nipple (2.5 mm2) VS 2.5 PA 003901000

local index:
TEG002ETIP
Catalog No:
003901000
EAN code:
5904722915091
Manufacturer: ETI POLAM
Rated current [A]: 415
Type: VS 2.5PA
Price:
0,89 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

For use, among others in low-voltage panels and junction and control boxes, in order to obtain functional and safe connections of electrical wires between electrical devices. Basic parameters, the knowledge of which is necessary for the proper operation of this type of products (i.e. connector type, rated voltage, permissible cable cross-section) are placed on each module.

Advantages:

  •  enclosures made of colored polyamide 66 (type VS) - non-flammable,
  •  rated current up to 415 A, →rated terminal cross-section from 2.5 up to 240 mm2;
  •  possibility of operation in temperatures from -40 to +100o C,
  •  possibility of bridging connectors,
  •  mounting on rail TH 15, TH 32, TH 35,
  •  the housing prevents the hand from touching live screws.

Technical data

  • Rated current [A]
    415
  • PKWIU
    27.33.13.0
  • Type
    VS 2.5PA

Other technical data

  • Connectable conductor cross section fine-strand without cable end sleeve
    0.5 ... 4 mm²
  • Rated current In
    24 A
  • Type of electrical connection 1
    Clip connection
  • Material insulation body
    Thermoplastic
  • Colour
    Beige
  • Connectable conductor cross section solid-core
    0.5 ... 4 mm²
  • Rated voltage
    660 V
  • Mounting method
    DIN rail (top hat rail) 35 mm
  • Closing plate required
    Yes

Bulk packaging

A kind of package Pudełko
Quantity 100 pcs.
Weight (kg) 0,679
Volume (m3) 0,001
Width (m) 0,180
Length (m) 0,135
Depth (m) 0,050
