Thread nipple ZG-G16 green A11-8405

local index:
TES057POKO
Catalog No:
A11-8405
EAN code:
5902626187781
Manufacturer: POKÓJ
Color: Green
Accurate color: Green
Outlet

Stan produktu: Towar jest fabrycznie nowy, nieuszkodzony. Może nosić ślady długiego magazynowania.

Opakowanie: Towar może zostać dostarczony w opakowaniu zastępczym lub w lekko uszkodzonym oryginalnym opakowaniu.

Dostępność: Tylko w ilości dostępnej na magazynie.

Price:
0,65 €
gross / pcs.
(including VAT 23%)
Last lowest price: 0,65 € gross
Base price: 3,05 € gross -79%
Delivery in 3h
Accessible 1 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
It is not possible to add more of this product to the cart. Goods at a promotional price can only be purchased in the quantity available in stock.
Add to clipboard
Print

Product description

Thread nipple ZG-G16 green

Technical data

  • Color
    Green
  • PKWIU
    27.12.40.0
  • Accurate color
    Green

Other technical data

  • Connectable conductor cross section fine-strand without cable end sleeve
    0.5 ... 10 mm²
  • Connectable conductor cross section solid-core
    0.5 ... 16 mm²
  • Rated current In
    76 A
  • Type of electrical connection 1
    Screw connection
  • Connection position
    Atop
  • Number of clamp positions per level
    2
  • Material insulation body
    Thermoplastic
  • Inflammability class of insulation material according to with UL94
    V2
  • Wysokość przy najniższym sposobie montażu
    42.6 mm
  • Explosion-tested version 'Ex e'
    No
  • Colour
    Green
  • Connectable conductor cross section fine-strand with cable end sleeve
    0.5 ... 10 mm²
  • Connectable conductor cross section multi-wired
    0.5 ... 10 mm²
  • Rated voltage
    690 V
  • Type of electrical connection 2
    Screw connection
  • Number of levels
    1
  • Mounting method
    DIN rail (top hat rail) 35 mm
  • Operating temperature
    -25 ... 100 °C
  • Width/grid dimension
    12 mm
  • Length
    44 mm
  • Closing plate required
    Yes
  • Internally connected stages
    No
