Creep resistance: KC > 600
Temperature resistance: 120°C
Un = 800 V at 2.5 and 4 mm2
Un = 400 V at 10 mm2 and larger
Possibility of connecting two conductors with the same cross-section under one terminal screw (in the case of PE only 1 conductor)
Easy wire entry into the open terminal thanks to the tapered entry
Easy to insert a screwdriver into the lowered clamping screws
Idling/idle after loosening clamping screws - especially important for power screwdrivers
All parts permanently fixed in the terminal carrier
The same level up to 35 mm2, in order to maintain the required insulation distances between individual groups of terminals, a partition/end plate should be placed at the beginning or end of a group of terminals.

Depth [mm]

5
Installation

For mounting on DIN EN 50022 rail
Height [mm]

48.5

Color

Yellow-green
Width [mm]

44.5
PKWIU

27.33.13.0

Other technical data

Type of electrical connection 1

Screw connection
Mounting method

Other
Closing plate required

No

Type of electrical connection 2

Screw connection
Material insulation body

Thermoplastic
Colour

Green/yellow

A kind of package		Karton	Paleta
Quantity	1 pcs.	100 pcs.	10000 pcs.
Weight (kg)	0,017	1,760	199,000
Width (m)	0,049	0,120	0,800
Length (m)	0,005	0,021	1,050
Depth (m)	0,049	0,157	1,200
