Spring plug raster 2.5mm 8-way light gray 733-108
local index:
TEB872WAGO
Catalog No:
733-108
EAN code:
4044918294119
Price:
504,46 €
gross / pkg.
(including VAT 23%)
5,04 € gross/pcs.
Delivery in 3h
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Universal clamp for all types of cables CAGE CLAMP can be operated on two levels for easy cable assembly and device wiring Possibility of individual mounting of plates and cable relief housings 100% protection against incorrect plugging Possibility of coding of plug-in elements
Technical data
-
Number of tracks1
-
Contact cover materialTin
-
Cross-section of connected single-wire cable [mm]0.08 - 0.5
-
Cross-section of the connected stranded wire with a ferrule [mm]0.25 - 0.34
-
Type of connecting cableRound cable
-
Series733
-
Degree of contamination2
-
Surge protector typeIII
-
Pitch [mm]2.5
-
Number of connectors8
-
ColorGray
-
Rated current [A]6
-
Cross-section of the connected stranded wire without ferrule [mm]0.08 - 0.5
-
Cross-section of connected multicore cable [mm]0.08 - 0.5
-
Type of electrical connectionSpring clip
-
Level of securityIP20
-
Pieces in the package100
-
Rated impulse voltage [kV]2.5
-
Accurate colorGray
Other technical data
-
Type of connectionPrinted circuit board to cable
-
Number of poles8
-
Modular spacing contacts2.5 mm
-
Angle contact/conductor connection180° (horizontal)
-
Rated voltage160 V
-
Over voltage categoryIII
-
Connectable conductor cross section fine-strand without cable end sleeve0.08 ... 0.5 mm²
-
Connectable conductor cross section solid-core0.08 ... 0.5 mm²
-
Type of electric connectionSpring clamp connection
-
Material of contact surfaceTin
-
Material insulation bodyThermoplastic
-
Coating housingNie dotyczy
-
Inflammability class of insulation material according to with UL94V0
-
Operating temperature-60 ... 100 °C
-
Contact typeBus
-
Number of plug-in contact rows1
-
Modular spacing connections2.5 mm
-
Rated current In6 A
-
Rated surge voltage2.5 kV
-
Pollution degree2
-
Connectable conductor cross section fine-strand with cable end sleeve0.25 ... 0.34 mm²
-
Connectable conductor cross section multi-wired0.08 ... 0.5 mm²
-
Connectable cable typeTubular cable
-
Material contactOther copper alloys
-
Housing materialPlastic
-
Housing colourGrey
-
With protective conductorNo
-
Degree of protection (IP), mountedIP20
Manufacturer details
-
ManufacturerWAGO ELWAG Sp. z o.o.
-
Address50-506 Wrocław Piękna 58A
-
E-mail
-
Tax identification number8961025689
-
GLN4017332000000
Bulk packaging
| A kind of package | Karton |
| Quantity | 1 pkg. |
| Weight (kg) | 0,596 |
| Volume (m3) | 0,003 |
| Width (m) | 0,256 |
| Length (m) | 0,318 |
| Depth (m) | 0,040 |
