Leakage resistance: KC > 600
Temperature resistance: 120°C
Un = 800 V at 2.5 and 4 mm2
Un = 400 V at 10 mm2 and larger
Possibility of connecting two conductors of the same cross-section to one terminal screw (in the case of PE only 1 conductor)
Easy wire entry into the open terminal thanks to the tapered entry
Easy to insert a screwdriver into the lowered clamping screws
Idle/idle after loosening clamp screws – especially important for mechanical screwdrivers
All parts permanently fixed in the carrier of the clamps
The same level up to 35 mm2, in order to maintain the required insulation distances between individual groups of terminals, or at the beginning or end of a group of terminals, a partition/end plate should be placed.

Depth [mm]

24
Installation

For mounting on DIN EN 50022 rail
Width [mm]

76.8
PKWIU

27.33.13.0

Color

Gray
Rated current [A]

192
Height [mm]

81.2

Other technical data

Rated current In

192 A
Type of electrical connection 2

Screw connection
Material insulation body

Thermoplastic
Closing plate required

No
Internally connected stages

No

Type of electrical connection 1

Screw connection
Mounting method

DIN rail (top hat rail) 35 mm
Explosion-tested version 'Ex e'

No
Colour

Grey

A kind of package		Karton	Paleta
Quantity	1 pcs.	20 pcs.	10000 pcs.
Weight (kg)	0,170	3,555	1800,500
Width (m)	0,024	0,160	0,800
Length (m)	0,080	0,085	1,050
Depth (m)	0,076	0,260	1,200
