Pass-through terminal 2.5mm2 vertical bridge KXA02VB

Indice locale:
TES114HAGE
Numero di catalogo:
KXA02VB
Codice EAN:
3250613942007
Produttore: HAGER
Energy lost in cables [W]: 1
Depth [mm]: 5
Color: Black
Prezzo:
5,39 €
gross / pezzi
(inclusa IVA 23%)
Consegna in 3 ore
fino a 10 settimane (giorni lavorativi)
Raccolta in 1h
Quantità pezzi
(multiplo:
1
)
Aggiungi agli appunti
Stampa

Descrizione del prodotto

Through terminal, vertical bridge, series screw terminals.

Series characteristics:

  • Resistance for creepage currents: KC > 600
  • Temperature resistance: 120°C
  • Possibility of connecting two wires of the same cross-section to one terminal screw (in the case of PE only 1 wire)
  • Easy cable entry into open terminal due to conical entry
  • Easy insertion of screwdriver into lowered terminal screws
  • Idling / freewheeling after loosening terminal screws - especially important for mechanical screwdrivers< /li>
  • All parts permanently fixed in the terminal carrier
  • Equal level up to 35 mm2, in order to maintain the required insulation distances between individual groups of terminals, a partition/end plate should be placed at the beginning or end of a group of terminals.

Dati tecnici

  • Energy lost in cables [W]
    1
  • Color
    Black
  • Rated current [A]
    24
  • Wire cross-section (cord) [mm²]
    0.5 - 2.5
  • PKWIU
    27.33.13.0
  • Depth [mm]
    5
  • Material
    Polyamide
  • power loss [W]
    1
  • Conductor cross-section (wire) [mm²]
    0.5 - 4

Altri dati tecnici

  • Rated current In
    24 A
  • Type of electrical connection 2
    Screw connection
  • Colour
    Black
  • Type of electrical connection 1
    Screw connection
  • Material insulation body
    Thermoplastic

Imballaggio sfuso

Una specie di pacchetto Karton Paleta
Quantità 1 pezzi 100 pezzi 10000 pezzi
Peso (kg) 0,014 1,460 148,500
Larghezza (m) - 0,117 0,800
Lunghezza (m) - 0,052 0,420
Profondità (m) - 0,240 1,200
