Copper cable connector without galvanic coating Z 10 100pcs. TOZAC0100000001

Indice locale:
TEB279RADP
Numero di catalogo:
TOZAC0100000001
Codice EAN:
5907511911007
Produttore: RADPOL
Pieces in the package: 100
Weight [kg/unit]: 0.0049
Prezzo:
200,26 zł
gross / conf.
(inclusa IVA 23%)
2,00 zł gross/pezzi
fino a 4 settimane
Su ordinazione
Quantità conf.
(multiplo:
1
)
Aggiungi alla richiesta di preventivo
Aggiungi agli appunti
Stampa

Descrizione del prodotto

Copper cable connectors are used to connect copper wires. They increase safety and durability  connections. For connecting the cores of copper cables “overlap´” copper cable connectors in parallel ZW are used. In the heating industry  ZCS fittings  4 are used to perform the installation  alarm pre-insulated pipes.

Dati tecnici

  • Pieces in the package
    100
  • PKWIU
    27.33.13.0
  • Weight [kg/unit]
    0.0049

Altri dati tecnici

  • Nominal cross section
    10 ... 10 mm²
  • Suitable for solid conductors
    Yes
  • Suitable for fine strand conductors
    Yes
  • Material
    Copper
  • Insulation
    None
  • Type of connection
    Percussion connector
  • Oil stop/centre bar
    No
  • Model
    Standard version
  • Suitable for stranded conductors
    Yes
  • Suitable for round conductors
    Yes
  • Surface protection
    Bare
  • Voltage level
    Up to 600 V
  • For pull protected connections
    Yes
