4-wire connector 1.5mm² red 279-833

local index:
TEB950WAGO
Catalog No:
279-833
EAN code:
4044918520522
Manufacturer: WAGO ELWAG
Stripping length [mm]: 0.33
Depth [mm]: 73
Color: Red
Outlet

Stan produktu: Towar jest fabrycznie nowy, nieuszkodzony. Może nosić ślady długiego magazynowania.

Opakowanie: Towar może zostać dostarczony w opakowaniu zastępczym lub w lekko uszkodzonym oryginalnym opakowaniu.

Dostępność: Tylko w ilości dostępnej na magazynie.

Price:
0,63 €
gross / pcs.
(including VAT 23%)
Last lowest price: 1,86 € gross
Base price: 1,93 € gross -67%
Delivery in 3h
Accessible 86 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
It is not possible to add more of this product to the cart. Goods at a promotional price can only be purchased in the quantity available in stock.
Add to clipboard
Print

Product description

4-wire connector 1.5 mm2 red

Technical data

  • Stripping length [mm]
    0.33
  • Color
    Red
  • Installation
    On the TH-35 rail
  • Series
    279
  • Wire connection technique
    CAGE CLAMP
  • Accurate color
    Red
  • Minimum stripping length [mm]
    8
  • Depth [mm]
    73
  • Number of potentials
    1
  • Gauge [AWG]
    28
  • Width [mm]
    4
  • Height [mm]
    27
  • Maximum stripping length [mm]
    9
  • Number of connectors
    4

Other technical data

  • Connectable conductor cross section fine-strand without cable end sleeve
    0.08 ... 1.5 mm²
  • Connectable conductor cross section multi-wired
    0.08 ... 1.5 mm²
  • Rated voltage
    800 V
  • Type of electrical connection 2
    Spring clamp connection
  • Number of levels
    1
  • Mounting method
    DIN rail (top hat rail) 35 mm
  • Operating temperature
    105 ... 105 °C
  • Width/grid dimension
    4 mm
  • Length
    73 mm
  • Closing plate required
    Yes
  • Internally connected stages
    No
  • Connectable conductor cross section solid-core
    0.08 ... 1.5 mm²
  • Rated current In
    18 A
  • Type of electrical connection 1
    Spring clamp connection
  • Connection position
    Atop
  • Number of clamp positions per level
    4
  • Material insulation body
    Thermoplastic
  • Inflammability class of insulation material according to with UL94
    V0
  • Wysokość przy najniższym sposobie montażu
    27 mm
  • Explosion-tested version 'Ex e'
    No
  • Colour
    Red

Bulk packaging

A kind of package Karton
Quantity 100 pcs.
Weight (kg) 0,708
Volume (m3) 0,001
Width (m) 0,165
Length (m) 0,227
Depth (m) 0,045
