3-wire connector 4mm² yellow 50pcs 281-686

local index:
TEB167WAGO
Catalog No:
281-686
EAN code:
4044918484978
Manufacturer: WAGO ELWAG
Depth [mm]: 73.5
Color: Yellow
Total number of potentials: 1
Price:
1,49 €
gross / pcs.
(including VAT 23%)
0,03 € gross/pcs.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

3-wire connector 4 mm2 yellow

Technical data

  • Depth [mm]
    73.5
  • Total number of potentials
    1
  • Surge voltage [kV]
    8
  • Gauge [AWG]
    28
  • Degree of contamination
    3
  • Pieces in the package
    50
  • Height[mm]
    29
  • Color
    Yellow
  • Installation
    On the TH-35 rail
  • Rated current [A]
    32
  • Series
    281
  • Width [mm]
    6
  • Wire connection technique
    CAGE CLAMP

Other technical data

  • Connectable conductor cross section fine-strand without cable end sleeve
    0.08 ... 4 mm²
  • Connectable conductor cross section multi-wired
    0.08 ... 4 mm²
  • Rated voltage
    800 V
  • Type of electrical connection 2
    Spring clamp connection
  • Number of levels
    1
  • Mounting method
    DIN rail (top hat rail) 35 mm
  • Operating temperature
    105 ... 105 °C
  • Width/grid dimension
    6 mm
  • Length
    73.5 mm
  • Closing plate required
    Yes
  • Internally connected stages
    No
  • Connectable conductor cross section solid-core
    0.08 ... 4 mm²
  • Rated current In
    32 A
  • Type of electrical connection 1
    Spring clamp connection
  • Connection position
    Atop
  • Number of clamp positions per level
    3
  • Material insulation body
    Thermoplastic
  • Inflammability class of insulation material according to with UL94
    V0
  • Wysokość przy najniższym sposobie montażu
    29 mm
  • Explosion-tested version 'Ex e'
    No
  • Colour
    Yellow

Bulk packaging

A kind of package Karton
Quantity 50 pcs.
Weight (kg) 0,583
Volume (m3) 0,001
Width (m) 0,097
Length (m) 0,335
Depth (m) 0,044
