3-wire connector 2.5mm² red 100pcs 280-653
Lokaler Index:
TEB143WAGO
Katalognummer:
280-653
EAN-Code:
4044918391184
Preis:
140,36 €
gross / pack
(inklusive MwSt 23%)
1,40 € gross/stk.
Lieferung in 3h
Abholung in 1 Stunde
Menge pack
(mehrere:
1
)
Zur Zwischenablage hinzufügen
Drucken
Fragen Sie nach dem Produkt
Produktbeschreibung
3-wire connector 2.5 mm2 red
Technische Daten
-
Stripping length [mm]0.33
-
ColorRed
-
Number of poles3
-
InstallationOn the TH-35 rail
-
Rated voltage EN [V]800
-
The plane of descriptionDescription in the middle
-
Gauge [AWG]28
-
Series280
-
Width [mm]5
-
Wire connection techniqueCAGE CLAMP®
-
Height [mm]28
-
Maximum stripping length [mm]9
-
Number of connectors3
-
Depth [mm]64
-
ConstructionHorizontal design
-
Total number of potentials1
-
Surge voltage [kV]8
-
Fire load [MJ]0.123
-
Rated current [A]24
-
Type of wiringFront wiring
-
Degree of contamination3
-
Pieces in the package100
-
Weight [g]7,576
-
Accurate colorRed
-
Minimum stripping length [mm]8
Weitere technische Daten
-
Connectable conductor cross section fine-strand without cable end sleeve0.08 ... 2.5 mm²
-
Connectable conductor cross section multi-wired0.08 ... 2.5 mm²
-
Rated voltage800 V
-
Type of electrical connection 2Spring clamp connection
-
Number of levels1
-
Mounting methodDIN rail (top hat rail) 35 mm
-
Operating temperature105 ... 105 °C
-
Width/grid dimension5 mm
-
Length64 mm
-
Closing plate requiredYes
-
Internally connected stagesNo
-
Connectable conductor cross section solid-core0.08 ... 2.5 mm²
-
Rated current In24 A
-
Type of electrical connection 1Spring clamp connection
-
Connection positionAtop
-
Number of clamp positions per level3
-
Material insulation bodyThermoplastic
-
Inflammability class of insulation material according to with UL94V0
-
Wysokość przy najniższym sposobie montażu28 mm
-
Explosion-tested version 'Ex e'No
-
ColourRed
Hersteller-Details
-
HerstellerWAGO GmbH & Co. KG
-
Adresse32423 Minden Hansastraße 27 Niemcy
-
E-Mail
Großpackungen
| Eine Art Paket | Karton |
| Menge | 1 pack |
| Gewicht (kg) | 0,830 |
| Volumen (m3) | 0,002 |
| Breite (m) | 0,138 |
| Länge (m) | 0,277 |
| Tiefe (m) | 0,048 |
