2-wire connector mounted to the ground ZGB-16/K yellow A16-0701 A16-0701

Name: 2-wire connector mounted to the ground ZGB-16/K yellow A16-0701
Brand: POKÓJ
SKU: TES219POKO
Price: 17.96 PLN
Availability: BackOrder

local index:

TES219POKO

Catalog number:

A16-0701

EAN code:

5902626103576

2-wire connector mounted to the ground ZGB-16/K yellow A16-0701

Click on the photo to enlarge

Manufacturer: POKÓJ

Price:

17,96 zł

gross / pcs.

(including VAT 23%)

up to 4 weeks

On request

Quantity pcs.

(multiplicity:

1

)

Add to inquiry

Add to clipboard

Print

Ask about the product

Technical data Manufacturer details Files to download

Technical data

PKWIU

27.12.40.0

Other technical data

Connectable conductor cross section fine-strand without cable end sleeve

2.5 ... 16 mm²
Connectable conductor cross section solid-core

2.5 ... 16 mm²
Rated current In

76 A
Type of electrical connection 1

Screw connection
Connection position

Atop
Number of clamp positions per level

2
Material insulation body

Thermoplastic
Inflammability class of insulation material according to with UL94

V2
Wysokość przy najniższym sposobie montażu

31 mm
Explosion-tested version 'Ex e'

No
Colour

Yellow

Connectable conductor cross section fine-strand with cable end sleeve

2.5 ... 16 mm²
Connectable conductor cross section multi-wired

2.5 ... 16 mm²
Rated voltage

690 V
Type of electrical connection 2

Screw connection
Number of levels

1
Mounting method

Direct mounting
Operating temperature

-25 ... 100 °C
Width/grid dimension

24 mm
Length

60 mm
Closing plate required

No
Internally connected stages

No
