2-wire connector 6mm² orange 282-902
local index:
TES055WAGO
Catalog No:
282-902
EAN code:
4044918445849
Price:
0,97 €
gross / pcs.
(including VAT 23%)
Last lowest price:
2,89 € gross
Price history for this product
1. 0,97 € gross / pcs.
2. Last lowest price:
2,89 €
3. Base price:
3,00 €
-68%
1. How much does this product cost today
2. Lowest price in the last 30 days
3. The base price of the product
Base price:
3,00 € gross
-68%
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
It is not possible to add more of this product to the cart. Goods at a promotional price can only be purchased in the quantity available in stock.
Add to clipboard
Print
Ask about the product
Product description
2-wire connector 6 mm2 orange
Technical data
-
Stripping length [mm]0.49
-
ColorSilver
-
Number of poles2
-
InstallationOn the TH-35 rail
-
Rated voltage EN [V]800
-
The plane of descriptionDescription in the middle
-
Gauge [AWG]24
-
Series282
-
Width [mm]8
-
Weight [g]15.906
-
Accurate colorOrange
-
Minimum stripping length [mm]12
-
Depth [mm]74.5
-
ConstructionHorizontal design
-
Total number of potentials1
-
Surge voltage [kV]8
-
Fire load [MJ]0.267
-
Rated current [A]41
-
Type of wiringFront wiring
-
Degree of contamination3
-
Wire connection techniqueCAGE CLAMP®
-
Height [mm]32.5
-
Maximum stripping length [mm]13
-
Number of connectors2
Other technical data
-
Connectable conductor cross section fine-strand without cable end sleeve0.2 ... 6 mm²
-
Connectable conductor cross section multi-wired0.2 ... 6 mm²
-
Rated voltage800 V
-
Type of electrical connection 2Spring clamp connection
-
Number of levels1
-
Mounting methodDIN rail (top hat rail) 35 mm
-
Operating temperature105 ... 105 °C
-
Width/grid dimension8 mm
-
Length74.5 mm
-
Closing plate requiredYes
-
Internally connected stagesNo
-
Connectable conductor cross section solid-core0.2 ... 6 mm²
-
Rated current In41 A
-
Type of electrical connection 1Spring clamp connection
-
Connection positionAtop
-
Number of clamp positions per level2
-
Material insulation bodyThermoplastic
-
Inflammability class of insulation material according to with UL94V0
-
Wysokość przy najniższym sposobie montażu32.5 mm
-
Explosion-tested version 'Ex e'No
-
ColourOrange
Manufacturer details
-
ManufacturerWAGO ELWAG Sp. z o.o.
-
Address50-506 Wrocław Piękna 58A
-
E-mail
-
Tax identification number8961025689
-
GLN4017332000000
Bulk packaging
| A kind of package | Karton |
| Quantity | 50 pcs. |
| Weight (kg) | 0,835 |
| Volume (m3) | 0,001 |
| Width (m) | 0,165 |
| Length (m) | 0,227 |
| Depth (m) | 0,045 |
