2-wire connector 2.5mm² yellow 280-906

local index:
TEB225WAGO
Catalog No:
280-906
EAN code:
4044918391962
Manufacturer: WAGO ELWAG
Product group: 1 (strip terminal blocks)
Color: Yellow
Number of potentials: 1
Outlet

Stan produktu: Towar jest fabrycznie nowy, nieuszkodzony. Może nosić ślady długiego magazynowania.

Opakowanie: Towar może zostać dostarczony w opakowaniu zastępczym lub w lekko uszkodzonym oryginalnym opakowaniu.

Dostępność: Tylko w ilości dostępnej na magazynie.

Price:
0,58 €
gross / pcs.
(including VAT 23%)
106,85 € gross/kg.
Last lowest price: 1,61 € gross
Base price: 1,69 € gross -66%
Delivery in 3h
Accessible 9 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
It is not possible to add more of this product to the cart. Goods at a promotional price can only be purchased in the quantity available in stock.
Add to clipboard
Print

Product description

2-wire feed-through terminal

Technical data

  • Product group
    1 (strip terminal blocks)
  • Number of potentials
    1
  • Gauge [AWG]
    2014-12-28 00:00:00
  • Series
    280
  • Dirt zone
    3
  • Rated impulse voltage [kV]
    8
  • Number of connectors
    2
  • Color
    Yellow
  • Rated current [A]
    24
  • Clamp type
    CAGE CLAMP
  • How to install the cable
    Front mounting
  • Weight [g]
    5.428
  • Accurate color
    Yellow

Other technical data

  • Connectable conductor cross section fine-strand without cable end sleeve
    0.08 ... 2.5 mm²
  • Connectable conductor cross section multi-wired
    0.08 ... 2.5 mm²
  • Rated voltage
    800 V
  • Type of electrical connection 2
    Spring clamp connection
  • Number of levels
    1
  • Mounting method
    DIN rail (top hat rail) 35 mm
  • Operating temperature
    105 ... 105 °C
  • Width/grid dimension
    5 mm
  • Length
    53 mm
  • Closing plate required
    Yes
  • Internally connected stages
    No
  • Connectable conductor cross section solid-core
    0.08 ... 2.5 mm²
  • Rated current In
    24 A
  • Type of electrical connection 1
    Spring clamp connection
  • Connection position
    Atop
  • Number of clamp positions per level
    2
  • Material insulation body
    Thermoplastic
  • Inflammability class of insulation material according to with UL94
    V0
  • Wysokość przy najniższym sposobie montażu
    28 mm
  • Explosion-tested version 'Ex e'
    No
  • Colour
    Yellow

Bulk packaging

A kind of package Karton
Quantity 100 pcs.
Weight (kg) 0,574
Volume (m3) 0,001
Width (m) 0,115
Length (m) 0,270
Depth (m) 0,037
