2-wire connector 16mm² blue 25pcs 283-604
local index:
TEG380WAGO
Catalog No:
283-604
EAN code:
4050821413141
Price:
79,26 €
gross / pkg.
(including VAT 23%)
3,17 € gross/pcs.
Delivery in 3h
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
2-wire feed-through terminal.
Technical data
-
ColorBlue
-
Pieces in the package25
-
Series283
Other technical data
-
Connectable conductor cross section fine-strand without cable end sleeve0.2 ... 16 mm²
-
Connectable conductor cross section multi-wired0.2 ... 16 mm²
-
Rated voltage800 V
-
Type of electrical connection 2Spring clamp connection
-
Number of levels1
-
Mounting methodDIN rail (top hat rail) 35 mm
-
Operating temperature105 ... 105 °C
-
Width/grid dimension12 mm
-
Length80 mm
-
Closing plate requiredYes
-
Internally connected stagesNo
-
Connectable conductor cross section solid-core0.2 ... 16 mm²
-
Rated current In76 A
-
Type of electrical connection 1Spring clamp connection
-
Connection positionAtop
-
Number of clamp positions per level2
-
Material insulation bodyThermoplastic
-
Inflammability class of insulation material according to with UL94V0
-
Wysokość przy najniższym sposobie montażu37.5 mm
-
Explosion-tested version 'Ex e'No
-
ColourBlue
Manufacturer details
-
ManufacturerWAGO ELWAG Sp. z o.o.
-
Address50-506 Wrocław Piękna 58A
-
E-mail
-
Tax identification number8961025689
-
GLN4017332000000
Bulk packaging
| A kind of package | Karton |
| Quantity | 1 pkg. |
| Weight (kg) | 0,852 |
| Volume (m3) | 0,001 |
| Width (m) | 0,095 |
| Length (m) | 0,320 |
| Depth (m) | 0,050 |
