2-wire connector 16mm² 283-104

local index:
TEB236WAGO
Catalog No:
283-104
EAN code:
4044918298360
Manufacturer: WAGO ELWAG
Color: Blue
Rated current [A]: 76
Gauge [AWG]: 2014-06-24 00:00:00
Price:
2,64 €
gross / pcs.
(including VAT 23%)
95,78 € gross/kg.
Delivery in 3h
Accessible 5 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

2-wire feed-through terminal.

Technical data

  • Color
    Blue
  • Gauge [AWG]
    2014-06-24 00:00:00
  • Series
    283
  • Weight [g]
    27.564
  • Accurate color
    Blue
  • Rated current [A]
    76
  • Clamp type
    CAGE CLAMP
  • Dirt zone
    3
  • Rated impulse voltage [kV]
    8

Other technical data

  • Connectable conductor cross section fine-strand without cable end sleeve
    0.2 ... 16 mm²
  • Connectable conductor cross section multi-wired
    0.2 ... 16 mm²
  • Rated voltage
    800 V
  • Type of electrical connection 2
    Spring clamp connection
  • Number of levels
    1
  • Mounting method
    DIN rail (top hat rail) 35 mm
  • Operating temperature
    105 ... 105 °C
  • Width/grid dimension
    12 mm
  • Length
    58 mm
  • Closing plate required
    Yes
  • Internally connected stages
    No
  • Connectable conductor cross section solid-core
    0.2 ... 16 mm²
  • Rated current In
    76 A
  • Type of electrical connection 1
    Spring clamp connection
  • Connection position
    Sideways
  • Number of clamp positions per level
    2
  • Material insulation body
    Thermoplastic
  • Inflammability class of insulation material according to with UL94
    V0
  • Wysokość przy najniższym sposobie montażu
    45.5 mm
  • Explosion-tested version 'Ex e'
    No
  • Colour
    Blue

Bulk packaging

A kind of package Karton
Quantity 50 pcs.
Weight (kg) 1,433
Volume (m3) 0,003
Width (m) 0,134
Length (m) 0,285
Depth (m) 0,072
