2-wire busbar terminal block with slide disconnector and measuring sockets 10 mm2 blue ZUG-G/P A11-9206 A11-9206

Name: 2-wire busbar terminal block with slide disconnector and measuring sockets 10 mm2 blue ZUG-G/P A11-9206
Brand: POKÓJ
SKU: TES186POKO
Price: 47.04 PLN
Availability: BackOrder

Indice locale:

TES186POKO

Numero di catalogo:

A11-9206

Codice EAN:

5902626102326

2-wire busbar terminal block with slide disconnector and measuring sockets 10 mm2 blue ZUG-G/P A11-9206

Clicca sulla foto per ingrandire

Produttore: POKÓJ

Prezzo:

47,04 zł

gross / pezzi

(inclusa IVA 23%)

2 settimane

Su ordinazione

Quantità pezzi

(multiplo:

1

)

Aggiungi alla richiesta di preventivo

Aggiungi agli appunti

Stampa

Chiedi informazioni sul prodotto

Dati tecnici Dettagli del produttore

Dati tecnici

Altri dati tecnici

Connectable conductor cross section fine-strand without cable end sleeve

0.5 ... 6 mm²
Connectable conductor cross section solid-core

0.5 ... 10 mm²
Rated current In

57 A
Type of electrical connection 1

Screw connection
Connection position

Sideways
Number of clamp positions per level

2
Mounting method

DIN rail (top hat rail) 35 mm
Inflammability class of insulation material according to with UL94

V2
Width/grid dimension

8 mm
Closing plate required

Yes
Type of slitting

Sliding
Length

77.2 mm

Connectable conductor cross section fine-strand with cable end sleeve

0.5 ... 6 mm²
Connectable conductor cross section multi-wired

0.5 ... 6 mm²
Rated voltage

690 V
Type of electrical connection 2

Screw connection
Number of levels

1
Internally connected stages

No
Material insulation body

Thermoplastic
Operating temperature

-25 ... 100 °C
Wysokość przy najniższym sposobie montażu

47.5 mm
Colour

Blue
With integrated test socket

Yes
