Universal optical cable EmiterNet J/A-DQ(ZN)H WBF 8G 50/125 OM2 AE02 LSZH KOEAE02008B5

local index:
KTR010EMSO
Catalog No:
KOEAE02008B5
EAN code:
5906764109339
Large-size product
Price:
5,15 zł
gross / m.
(including VAT 23%)
Delivery in 3h
Product on individual request
Pickup in 1h
Quantity m.
(multiplicity:
1
)
Add to inquiry
Print

Product description

Used in telecommunications, computer data transmission networks, CATV networks. The cable is suitable for laying - with the use of special pipes - in the ground (thanks to "dry" sealing and protection against mechanical damage, e.g. thanks to the use of fiberglass). These cables can be run in all planes of telecommunications networks, using guides, cable ducts, concrete ducts, and excellent mechanical parameters such as strength and bending radius do not cause problems when routing cables inside buildings. The cables have a sheath made of polyethylene resistant to UV radiation and flame retardant and halogen-free LS0H.

Technical data

Other technical data

  • Number of fibres
    8
  • Number of fibres per tube
    8
  • Category
    OM2
  • Armouring
    No
  • Material outer sheath
    Other
  • Colour outer sheath
    Black
  • Cable metal free
    Yes
  • Halogen free according to EN 60754-1/2
    Yes
  • Low smoke (according to EN 61034-2)
    Yes
  • Resistant to chemicals
    No
  • Outer diameter approx.
    5.4 mm
  • Suitable for underground installation
    Yes
  • Type of tube
    Loose tube
  • Fibre type
    Multi mode 50/125
  • With strain relief
    No
  • With rodent protection
    Yes
  • Specification material outer sheath
    Polyethylene (PE)
  • Longitudinal water blocking cable
    Yes
  • Reaction-to-fire according to EN 13501-6: Class
    Fca
  • Flame retardant
    According to IEC/EN 60332-1-2
  • Oil resistant according to EN IEC 60811-404
    No
  • UV resistant
    Yes
  • Min. permitted bending radius, stationary application/permanent installation
    81 mm
  • Blow in
    No

Manufacturer details

  • Manufacturer
    Emiter Sp. z o.o.
  • Address
    40-241 Katowice Porcelanowa 27 Polska
