Halogen Free Fire Retardant HDGs 4x1.5 Power Cable FE180/PH90 B50010

Index local:
KTK218BITN
Numéro de catalogue:
B50010
Code EAN:
5902956188113
Producteur: BITNER
Permissible core temperature during short-circuit [°C]: 250
Number of veins: 4
Color: Red
Prix:
2,29 €
gross / mc.
(y compris la TVA 23%)
Livraison en 3h
Accessible 10 mc.
Ramassage en 1h
Quantité mc.
(plusieurs:
1
)
Ajouter à la demande de devis
Ajouter au presse-papiers
Imprimer

Description du produit

Halogen-free fire-resistant cables are intended for use in places where it is necessary to ensure the functioning of devices during a fire. Recommended for use in emergency lighting systems, smoke extraction systems, alarm systems, signaling systems, voice alarm systems, control systems, fire alarm systems and fire automation as well as in other circuits ensuring safety. In fire conditions, these cables ensure proper functioning of the installation for at least 90 minutes. (PH90) and durability of insulation for 180 min. (FE180). During combustion, they do not emit toxic, suffocating gases and dense smoke. The cables are suitable for permanent installation inside buildings.

Données techniques

  • Permissible core temperature during short-circuit [°C]
    250
  • Color
    Red
  • Vein material
    Copper
  • AC standard voltages [V]
    2000
  • Rated voltage [V]
    300/500
  • Core
    Wire
  • Outer diameter [mm]
    9.1
  • Laying temperature range [°C]
    -0.2
  • Insulation material
    Halogen-free material
  • Number of veins
    4
  • Maximum operating temperature [°C]
    90
  • Minimum bending radius [mm]
    10 x diameter
  • Standard DC voltages [V]
    5000
  • Core cross-section [mm²]
    1.5
  • Insulation resistance [MΩ]
    100
  • Operating temperature range [°C]
    -0.375
  • Accurate color
    Red
  • PKWIU
    27.32.13

Détails du fabricant

  • Producteur
    BITNER Zakłady Kablowe Sp. z o.o.
  • Adresse
    30-009 Kraków ul. Friedleina 3/3
  • Numéro identifiant TVA
    6372159473
