Fireproof power cable without protective conductor HDGs 2x1mm2 B52000

Fireproof power cable without HDGs protective conductor, halogen-free, from the manufacturer BITNER. Product part number is B52000.

• 2-wire: blue, brown.
• Operating temperature:
  • During operation : -30°C to 80°C.
  • Minimum laying temperature: -10°C.
• Permissible core temperature: 90°C.
• Test voltage:
  • AC voltage: 3000V.
  • DC voltage: 7200V.
• Insulation resistance (min.): 100MΩxkm.
• Minimum bending radius: 10xØ.
• Conductors: solid copper class 1 (according to PN-EN 60228, EN 60228, IEC 60228).
• Flame retardant.
• No corrosive gases.
• Low smoke emission.
• Increased insulation durability (FE180).
• Cable function maintenance (PH120).
• Low fire load (heat of combustion).
