The time relay is used for time control in industrial and home automation systems (e.g. ventilation, heating, lighting, signaling, etc.). The relay has a hold function for up to 10 minutes. and switching the contact after a power failure.
Technical data
Number of contacts
0NO 0NC
Dimensions
1 module (18mm)
Package width [mm]
20
Rated control voltage Us for AC 50Hz [V]
12-264
Control circuit voltage [V]
12-264
Package height [mm]
150
Package weight [kg]
0.2
PKWIU
26.52.24.0
Other technical data
Type of electric connection
Screw connection
Function delay on de-energization
Yes
Function floating contact on de-energization
No
Function flashing, starting with pause, fixed time
No
Clock function, starting with pause, variable
No
Z gniazdem wtykowym
No
Suitable as remote control
No
Rated control supply voltage AC 50 Hz
12 ... 264 V
Rated control supply voltage DC
12 ... 264 V
Time range
0.1 ... 3600 s
With semiconductor output
No
Height
90 mm
Function delay-on energization
Yes
Function floating contact on energization
No
Function pulse shaping
No
Function flashing, starting with pulse, fixed time
