Thermistor machine protection, EMT6-DBK 066168

local index:
APN124MOEL
Catalog No:
066168
EAN code:
4015080661689
Manufacturer: EATON
Rated voltage [V]: 230
Rated current [A]: 3
Price:
270,76 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Multifunction device
Switch: lockable / non-reclosed
Trip on short circuit of sensor wires
Power failure proof
Remote or local reset
TEST button
Possibility to disable the detection of power failure and short circuit in the sensor circuit
LED indicators: network, error

Technical data

  • Rated voltage [V]
    230
  • Rated current [A]
    3

Other technical data

  • Type of electric connection
    Screw connection
  • Rated control supply voltage AC 60 Hz
    24 ... 240 V
  • Voltage type for actuating
    AC/DC
  • Number of measuring circuits
    1
  • External reset possible
    Yes
  • Number of contacts as normally open contact
    1
  • Temperature measuring range
    0 ... 0 °C
  • Width
    23 mm
  • Depth
    103 mm
  • Rated control supply voltage AC 50 Hz
    24 ... 240 V
  • Rated control supply voltage DC
    24 ... 240 V
  • With detachable clamps
    No
  • Error registration possible
    Yes
  • Number of contacts as normally closed contact
    1
  • Number of contacts as change-over contact
    0
  • Resistance measuring range
    750 ... 12000 Ω
  • Height
    83 mm

Bulk packaging

A kind of package Skrzynia
Quantity 1 pcs.
Weight (kg) 0,152
Volume (m3) 0,000
Width (m) 0,085
Length (m) 0,110
Depth (m) 0,027
