Switch (make and break contacts) KS 216 002421521

local index:
ALB103ETIP
Catalog No:
002421521
EAN code:
5904722903111
Manufacturer: ETI POLAM
Work category: AC-22A
Number of poles: 2
Rated current [A]: 16
Price:
15,07 €
gross / pcs.
(including VAT 23%)
188,38 € gross/kg.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

The system of installation switches and signaling lamps EVESYS is intended for installation in switchgears adapted to modular apparatus. They are used for switching on, switching off, switching and signaling in electrical circuits, e.g. control, signaling, control, etc. The switches can be sealed in the on and off position.

Advantages:
→ the family of installation switches and control lamps extends the EVE modular switchgear system,
→ all connectors and lamps are made in a modular form - module width 18 mm.
→ the distance between the contacts of the switches in the open state is greater than 3 mm,
→ switches and lamps are equipped with windows for attaching labels denoting the circuit in which they are installed.

Technical data

  • Work category
    AC-22A
  • Rated current [A]
    16
  • Weight [g]
    80
  • Number of poles
    2
  • Type
    KS 216
  • PKWIU
    27.12.23.0

Other technical data

  • Switching function
    Control switch
  • Rated current
    16 A
  • Voltage type
    AC/DC
  • Width in number of modular spacings
    1
  • Degree of protection (IP)
    IP20
  • Number of poles
    2
  • Rated voltage
    230 V
  • With signal lamp
    No
  • Built-in depth
    68 mm
