Switch I-0-II supply top 2P 40A SFT240

local index:
ALI034HAGE
Catalog No:
SFT240
EAN code:
3250615510921
Manufacturer: HAGER
Depth [mm]: 70
Number of modules: 2
Number of poles: 2
Price:
30,36 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Switch I-0-II supply top 2P 40A

Technical data

  • Depth [mm]
    70
  • Number of poles
    2
  • Rated insulation voltage [V]
    440
  • Power dissipation [W]
    4
  • Height [mm]
    83
  • PKWIU
    27.33.11.0
  • Number of modules
    2
  • Rated voltage [V]
    230
  • Rated current [A]
    40
  • Width [mm]
    35
  • Number of modules
    2

Other technical data

  • Switching function
    Two-way switch
  • Number of contacts as normally closed contact
    0
  • Number of poles
    2
  • Rated voltage
    230 V
  • Rated switching capacity
    0.846 kA
  • Voltage type
    AC
  • Max. lamp power
    0 W
  • Built-in depth
    70 mm
  • Number of contacts as normally open contact
    0
  • Number of contacts as change-over contact
    2
  • Rated current
    40 A
  • Min. rated voltage
    230 V
  • Short-circuit breaking capacity (Icw)
    0.6 kA
  • With signal lamp
    No
  • Width in number of modular spacings
    2
  • Degree of protection (IP)
    IP20

Bulk packaging

A kind of package Karton Pakiet Paleta
Quantity 1 pcs. 1 pcs. 60 pcs. 1440 pcs.
Weight (kg) 0,131 0,147 9,135 242,240
Width (m) 0,035 0,082 0,321 0,800
Length (m) 0,083 0,041 0,221 1,034
Depth (m) 0,075 0,098 0,383 1,200
