Size 3 switch disconnector, 630A, three-pole, screw connection M10 LTL3-3/9 001701251

local index:
ALI025ETIP
Catalog No:
001701251
Manufacturer: ETI POLAM
Rated voltage [V]: 690
Rated current [A]: 630
Weight [g]: 4800
Price:
34,17 €
gross / pcs.
(including VAT 23%)
7,12 € gross/kg.
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

HVL EK 000 box fuse switch disconnectors are low voltage devices that allow you to switch on and off an electric circuit under load, depending on the voltage and work category. They are also designed to protect the electric circuit in cooperation with fuses of the size WT - 00C (000). They can cooperate with installation short-circuits (e.g. NVL00, IZ00) acting as a disconnector. Specially designed main contacts (copper, silver-plated) with arc chambers ensure high switching capacity and long mechanical and electrical durability. HVL EK 000 fuse switch disconnectors are adapted for direct connection of wires using clamps - clamp OS00, prism P00 and P002 and for wires with a cable end - clamp - M8 screw.

HVL EK 000 fuse switch disconnectors can be mounted on a mounting plate (using M6 screws). Mounting position - vertical

Technical data

  • Rated voltage [V]
    690
  • Weight [g]
    4800
  • Rated current [A]
    630
  • PKWIU
    27.12.21.0

Other technical data

  • Version as main switch
    Yes
  • Max. rated operation voltage Ue AC
    690 V
  • Suitable for fuses
    NH000, NH00
  • With error protection
    No
  • Suitable for floor mounting
    Yes
  • Degree of protection (IP), front side
    IP20
  • Version as safety switch
    Yes
  • Rated permanent current Iu
    160 A
  • Number of poles
    3
  • Type of electrical connection of main circuit
    Frame clamp
  • Type of control element
    Cover grip
