Shunt release h250-h1600 100-120VAC HXC003H

local index:
ALA167HAGE
Catalog No:
HXC003H
EAN code:
3250613369439
Manufacturer: HAGER
Maximum input power [VA]: 1.68
Level of security: IP4X
power loss [W]: 1.7
Price:
113,25 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Shoulder release:

  • size: h250-h1600
  • rated operational voltage Ue (AC): 100-120V

Technical data

  • Maximum input power [VA]
    1.68
  • power loss [W]
    1.7
  • Rated switching voltage [V]
    100/120
  • Level of security
    IP4X
  • Connection type
    With a screw
  • PKWIU
    27.33.11.0

Other technical data

  • Rated control supply voltage AC 50 Hz
    100 ... 120 V
  • Rated control supply voltage DC
    0 ... 0 V
  • Initial value of the undelayed short-circuit release - setting range
    0 A
  • Type of electric connection
    Screw connection
  • Number of contacts as normally closed contact
    0
  • Suitable for power circuit breaker
    Yes
  • Suitable for motor safety switch
    No
  • Rated control supply voltage AC 60 Hz
    100 ... 120 V
  • Voltage type for actuating
    AC
  • End value adjustment range undelayed short-circuit release
    0 A
  • Number of contacts as normally open contact
    0
  • Number of contacts as change-over contact
    0
  • Suitable for off-load switch
    Yes
  • Suitable for overload relay
    No

Bulk packaging

A kind of package Karton Pakiet Paleta
Quantity 1 pcs. 1 pcs. 48 pcs. 1152 pcs.
Weight (kg) 0,064 0,065 3,560 110,440
Width (m) 0,080 0,080 0,321 0,800
Length (m) 0,040 0,041 0,219 1,026
Depth (m) 0,095 0,094 0,369 1,200
