Power source switch 125A three-pole + N (switchable with a knob on the disconnector) PRZK-4125N\W02

Índice local:
ALK993SPAM
Número de catálogo:
PRZK-4125N\W02
Código EAN:
5907723010154
Fabricante: SPAMEL
Continuous current [A]: 125
Insulation voltage [V]: 690
Precio:
1142,23 zł
gross / uds.
(IVA incluido 23%)
Entrega en 3h
hasta una semana (días laborables)
Recogida en 1h
Cantidad uds.
(múltiple:
1
)
Añadir a solicitud de presupuesto
Añadir al portapapeles
Imprimir

Descripción del producto

PRZK power source switches are built on the basis of RSI disconnectors, therefore they have all the features of these disconnectors. PRZK switches are a structural connection, with one common cover, of two RSI type disconnectors. This solution ensures excellent rigidity of the system, and thus, operational reliability and safety of use.

Datos técnicos

  • Continuous current [A]
    125
  • Insulation voltage [V]
    690

Otros datos técnicos

  • Model
    Reverser
  • With zero (off) position
    Yes
  • Rated permanent current Iu
    125 A
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as change-over contact
    0
  • Suitable for front mounting
    No
  • Suitable for intermediate mounting
    Yes
  • Housing material
    Plastic
  • Type of electrical connection of main circuit
    Screw connection
  • Number of poles
    3
  • With retraction in 0-position
    No
  • Degree of protection (IP), front side
    IP65
  • Number of auxiliary contacts as normally open contact
    0
  • Suitable for floor mounting
    Yes
  • Suitable for distribution board installation
    No
  • Complete device in housing
    No
  • Type of control element
    Turn button
