Power circuit breaker x160 3P 40kA 125A HNA125H
local index:
ALP040HAGE
Catalog No:
HNA125H
EAN code:
3250613130855
Price:
470,36 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Power switches:
• equipped with thermal-magnetic releases
• regulation of the thermal element in the range from 0.63 to 1xIn
• permanent magnetic member 10xIn
• compliant with IEC 60947-2 Features:
• mounting on a TS35 rail or mounting plate
• standard cage clamps for connecting copper wires
• cage clamps for aluminum conductors available as accessories
• equipped with thermal-magnetic releases
• regulation of the thermal element in the range from 0.63 to 1xIn
• permanent magnetic member 10xIn
• compliant with IEC 60947-2 Features:
• mounting on a TS35 rail or mounting plate
• standard cage clamps for connecting copper wires
• cage clamps for aluminum conductors available as accessories
Technical data
-
CharacteristicTM
-
Number of poles3
-
Rated insulation voltage [V]690
-
power loss [W]33
-
Electromagnetic release setting10
-
Number of modules4.5
-
Surge voltage [kV]8000
-
Rated current [A]125
-
Number of modules4.5
-
PKWIU27.12.22.0
Other technical data
-
Rated permanent current Iu125 A
-
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz40 kA
-
Adjustment range undelayed short-circuit release1500 ... 1500 A
-
Type of electrical connection of main circuitScrew connection
-
Suitable for DIN rail (top hat rail) mountingYes
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as change-over contact0
-
Number of poles3
-
Type of control elementToggle
-
Motor drive integratedNo
-
Degree of protection (IP)IP40
-
Rated voltage220 ... 415 V
-
Overload release current setting80 ... 125 A
-
Integrated earth fault protectionNo
-
Device constructionBuilt-in device fixed built-in technique
-
DIN rail (top hat rail) mounting optionalNo
-
Number of auxiliary contacts as normally open contact0
-
With switched-off indicatorYes
-
Position of connection for main current circuitFront side
-
Complete device with protection unitYes
-
Motor drive optionalNo
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta | |
| Quantity | 1 pcs. | 1 pcs. | 9 pcs. | 216 pcs. |
| Weight (kg) | 0,960 | 1,020 | 9,635 | 254,240 |
| Width (m) | 0,075 | 0,130 | 0,320 | 0,800 |
| Length (m) | 0,096 | 0,090 | 0,215 | 1,050 |
| Depth (m) | 0,130 | 0,170 | 0,365 | 1,200 |
