Narrow profile interface relay: 1P - one changeover contact PIR6WB-1PS-24VDC-R 857485

local index:
APE560RELP
Catalog No:
857485
Manufacturer: RELPOL
Level of security: IP20
Width [mm]: 6.2
Pieces in the package: 10
Price:
146,90 €
gross / pkg.
(including VAT 23%)
14,69 € gross/pcs.
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Narrow profile interface relay: 1P - one changeover contact. Width 6.2mm. Spring clamps. Output (replaceable - relay RM699BV, "R" code): 1P contacts - terminals: 11-12-14; AC1 - 6A / 230V; DC1 - 6 A / 24 V. Input - terminals: A1 - A2 - any polarity, supply voltage Un - 24 V DC. Dimensions: 98.3 x 6.2 x 84.6mm. Mounting on a 35 mm rail. IP 20.

Technical data

  • Level of security
    IP20
  • Pieces in the package
    10
  • Width [mm]
    6.2

Other technical data

  • Type of electric connection
    Spring clamp connection
  • Rated control supply voltage AC 60 Hz
    0 ... 0 V
  • Voltage type for actuating
    DC
  • Drive, switching attitude
    Mono stable
  • Type of switch contact
    Single contact
  • Degree of protection (IP)
    IP20
  • Height
    98.3 mm
  • Rated control supply voltage AC 50 Hz
    0 ... 0 V
  • Rated control supply voltage DC
    24 ... 24 V
  • Drive, polarization
    Polarity free
  • Number of contacts as change-over contact
    1
  • Complete with socket
    Yes
  • Width
    6.2 mm
  • Depth
    84.6 mm
