Interface relay: 2P - two changeover contacts PI84-012DC-00LD 854909
local index:
API811RELP
Catalog No:
854909
EAN code:
5900005165344
Price:
12,98 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Interface relay: 2P - two changeover contacts. Width 15.9mm. Circuit separation - input / output. Green LED indicator. Surge suppression diode D. screw terminals. Output: 2P contacts - terminals: 11-12-14; 21-22-24; AC1 - 8A / 250V; DC1 - 8 A / 24 V. Input - terminals: (+)A1 - (-)A2, supply voltage Un - 12 V DC. Dimensions: 78.1 x 15.9 x 66.5mm. Mounting on a 35 mm rail or on a mounting plate with one M3 screw. The set includes a GZM80 - IP 20 socket.
Technical data
-
Level of securityIP20
-
Width [mm]15.9
Other technical data
-
Type of electric connectionScrew connection
-
Rated control supply voltage AC 60 Hz0 ... 0 V
-
Voltage type for actuatingDC
-
Drive, switching attitudeMono stable
-
Type of switch contactSingle contact
-
Degree of protection (IP)IP20
-
Height78.1 mm
-
Rated control supply voltage AC 50 Hz0 ... 0 V
-
Rated control supply voltage DC12 ... 12 V
-
Drive, polarizationPolarity free
-
Number of contacts as change-over contact2
-
Complete with socketYes
-
Width15.9 mm
-
Depth66.5 mm
