Installation relay, Z-TN24/4S 267978

local index:
APN059MOEL
Catalog No:
267978
EAN code:
4015082679781
Manufacturer: EATON
Rated frequency [Hz]: 50
Depth [mm]: 60
Number of contacts: 4NO
Price:
117,91 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description


The Z-TN24/4S installation relay is designed to control the main and auxiliary circuits. Thanks to its universal purpose, it can be used both in residential and industrial construction.


The device allows you to manually set the operating mode using a special switch located on the front of the product.


The Z-TN24/4S relay is a monostable model. Contains four make contacts (NO). The small switch installed on the front of the device can be set to one of three available modes: ON (on, permanent on), OFF (off) and AUTOM (automatic operation). According to the parameters provided by the manufacturer, the nominal voltage of the coil is 24V DC. Contacts arranged according to the 4PST-NO configuration. The maximum switched voltage is 250V AC. The product can operate at temperatures from -20 to +45 degrees Celsius. The maximum operating current is 20A. The rated frequency of the product is 50Hz. The degree of protection is specified as IP20.


The installation relay Z-TN24/4S is suitable for easy rail mounting (type TH-35, DIN rail). The device is fixed with traditional clamping screws. The height of the product is 9 centimeters, the width is 3.5 centimeters, and the depth is 6 centimeters. The whole thing is made of high-quality white plastic.

Technical data

  • Rated frequency [Hz]
    50
  • Number of contacts
    4NO
  • Installation
    On the TH-35 rail
  • Level of security
    IP20
  • Width in modules
    2
  • Type
    Z-TN
  • Version
    Monostable
  • Height [mm]
    90
  • Depth [mm]
    60
  • Fixing
    screw terminals
  • Rated voltage [V]
    230
  • Width [mm]
    35
  • Working temperature [°C]
    from -20 to 45
  • Relay type
    installation
  • properties
    ON/AUTO/OFF
  • Rated control voltage [V]
    24

Other technical data

  • Function
    Mechanical
  • Width in number of modular spacings
    2
  • Number of contacts as normally open contact
    4
  • Number of contacts as change-over contact
    0
  • Type of control voltage 1
    AC
  • Control voltage 2
    0 ... 0 V
  • Frequency control voltage 2
    0 ... 0 Hz
  • Supply voltage
    250 ... 250 V
  • Max. incandescent lamp load
    0 W
  • Max. load fluorescent lamp (Duo circuit)
    0 VA
  • Max. switching current (cos phi = 0.6)
    0 A
  • Mounting method
    DIN rail
  • Built-in depth
    60 mm
  • Number of contacts as normally closed contact
    0
  • Control voltage 1
    24 ... 24 V
  • Frequency control voltage 1
    50 ... 50 Hz
  • Type of control voltage 2
    AC/DC
  • Rated current
    20 A
  • Voltage type (supply voltage)
    AC
  • Max. load fluorescent lamp
    0 VA
  • Max. load fluorescent lamp (parallel compensated)
    0 VA

Bulk packaging

A kind of package Skrzynia Karton
Quantity 1 pcs. 60 pcs.
Weight (kg) 0,277 16,819
Volume (m3) 0,000 0,017
Width (m) 0,037 0,190
Length (m) 0,092 0,385
Depth (m) 0,075 0,235
