Industrial relay R15-2313-23-5110-WT 804516

Electromagnetic relay, industrial - small size, for plug socket. Width 35mm. Output: 3P - three changeover contacts - terminals: 11(1), 12(4), 14(3); 21(6), 22(5), 24(7); 31(11), 32(8), 34(9); AC1 - 10A / 250V; DC1 - 10 A / 24 V. Input / coil - terminals: (+)A1(2) - (-)A2(10), supply voltage Un - 110 V AC. Mechanical indicator W, test button T - with contact blocking function. Dimensions: 35x35x54.4mm. IP 40. Contact material: AgNi/Au жесткое золочение. Dimensions of the set R15 3P + socket PZ11 + clamp PZ11 0031: 68.2 x 38 x 82.6 mm. Kit - IP 20. Dimensions of other kits are indicated in the description of the selected socket.
