Industrial, multifunctional time relay PIR153-024DC-00T 855535
local index:
APE545RELP
Catalog No:
855535
EAN code:
5900005165238
Manufacturer:
RELPOL
Level of security: IP20
Price:
89,00 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Industrial, multifunctional time relay: 3P - three changeover contacts. Functions: E, E(S), Wu, Wu(S), Bi, Bi(S), Bp, Bp(S), R, Ws, Wa, Es. Input - terminals: (+)A1 - (-)A2; external control contact S - terminals: (+)A1 - B1, supply voltage Un - 24 V DC. Output: 3P contacts - terminals: 11-12-14, 21-22-24, 31-32-34; AC1 - 10A / 250V, DC1 - 10A / 24V. Dimensions: 75 x 38 x 83.1 mm. Mounting on a 35 mm rail or on a mounting plate with two M3 screws. IP 20.
Technical data
-
Level of securityIP20
Other technical data
-
Type of electric connectionScrew connection
-
Function delay on de-energizationYes
-
Function floating contact on de-energizationYes
-
Function pulse shapingNo
-
Function flashing, starting with pulse, fixed timeYes
-
Clock function, starting with pulse, variableNo
-
Remote operation possibleNo
-
Pluggable on auxiliary contact blockNo
-
Rated control supply voltage AC 60 Hz0 ... 0 V
-
Voltage type for actuatingDC
-
Number of outputs, delayed, change-over contact3
-
With semiconductor outputNo
-
Height85.4 mm
-
Function delay-on energizationYes
-
Function floating contact on energizationYes
-
Function star-deltaNo
-
Function flashing, starting with pause, fixed timeYes
-
Clock function, starting with pause, variableNo
-
Z gniazdem wtykowymYes
-
Suitable as remote controlNo
-
Rated control supply voltage AC 50 Hz0 ... 0 V
-
Rated control supply voltage DC24 ... 24 V
-
Time range0 ... 0 s
-
Outputs, reversible delayed/undelayedNo
-
Width38.2 mm
-
Depth73 mm
Manufacturer details
-
ManufacturerRELPOL S.A.
-
Address68-200 Żary 11 Listopada 37
-
Phone number
-
E-mail
-
Tax identification number9280007076
-
GLN5909000713000
