Impulse Relay, 48AC/24DC, 4 NO, 16A, 50Hz, 2JC 100665

Name: Impulse Relay, 48AC/24DC, 4 NO, 16A, 50Hz, 2JC
Brand: EATON
SKU: API128MOEL
Price: 124.54 PLN

local index:

API128MOEL

Catalog No:

100665

EAN code:

4015081005666

Impulse Relay, 48AC/24DC, 4 NO, 16A, 50Hz, 2JC

Click on the photo to enlarge

Manufacturer: EATON

Frequency [Hz]: 50 - 50

Voltage [V]: 48 - 48

Type of voltage: AC

See full description

Price:

124,54 €

gross / pcs.

(including VAT 23%)

Delivery in 3h

up to 4 weeks (business days)

Pickup in 1h

Quantity pcs.

(multiplicity:

)

Add to clipboard

Ask about the product

Product description Technical data Manufacturer details Bulk packaging

Product description

Impulse relay, control voltage 48V AC / 24V DC, function: 4 NO contacts, rated current at 250V AC according to IEC/EN 60669-2-2: 16A, plug mounting dimensions 45mm, mounting width 2JC (35mm), switch current, terminal cross-section 0.5-10 mm² single and stranded / 0.5-6 mm² fine-wire with end sleeve

Technical data

Frequency [Hz]

50 - 50
Type of voltage

AC

Voltage [V]

48 - 48
Installation depth [mm]

60

Other technical data

Function

Mechanical switch
Width in number of modular spacings

2
Number of contacts as normally open contact

4
Number of contacts as change-over contact

0
Type of control voltage 1

AC
Control voltage 2

0 ... 0 V
Frequency control voltage 2

0 ... 0 Hz
Supply voltage

24 ... 415 V
Max. incandescent lamp load

2024 W
Max. load fluorescent lamp (Duo circuit)

2500 VA
Max. switching current (cos phi = 0.6)

24 A

Mounting method

DIN rail
Built-in depth

60 mm
Number of contacts as normally closed contact

0
Control voltage 1

48 ... 48 V
Frequency control voltage 1

50 ... 50 Hz
Type of control voltage 2

AC
Rated switch current

16 A
Voltage type (supply voltage)

AC
Max. load fluorescent lamp

2500 VA
Max. load fluorescent lamp (parallel compensated)

2500 VA
Suitable for manual operation

Yes

Manufacturer details

Manufacturer

EATON Electric Sp. z o.o.
Address

80-299 Gdańsk ul. Galaktyczna 30
E-mail

pl-gdansk@eaton.com
WWW

https://www.moeller.pl
Tax identification number

5841022327
GLN

5900009970944

Bulk packaging

A kind of package		Skrzynia	Karton
Quantity	1 pcs.	1 pcs.	60 pcs.
Weight (kg)	0,263	0,277	16,819
Volume (m3)	0,000	0,000	0,017
Width (m)	0,035	0,037	0,190
Length (m)	0,080	0,092	0,385
Depth (m)	0,070	0,075	0,235
