GZM92 plug-in socket for RM87N relays 857410

local index:
APG053RELP
Catalog No:
857410
Manufacturer: RELPOL
Color: Black
Level of security: IP20
Width [mm]: 15.9
Price:
47,83 €
gross / pkg.
(including VAT 23%)
4,78 € gross/pcs.
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print

Product description

GZM92 plug-in socket for RM87N relays, black color, width 15.9 mm. Circuit separation - coil terminals on one side and contact terminals on the opposite side of the socket. Input / coil - terminals: A1 - A2. Output / contacts - terminals: 11-12-14; COM terminal on the lower level. Track load capacity: 12 A / 300 V AC. Mounting on a 35 mm rail or on a mounting plate with one M3 screw. Dimensions of the GZM92 + RM87N + GZT80-0040 set: 78.1 x 15.9 x 66.5 mm. Note: a clamp type GZT80-0040 must be ordered separately for the socket, the so-called ejector, made of plastic. Signaling / surge protection modules type M... can be installed in the socket; Set - IP 20.

Technical data

  • Color
    Black
  • Width [mm]
    15.9
  • Accurate color
    Black
  • Level of security
    IP20
  • Pieces in the package
    10
