Four-pole load switch 630A HA458
local index:
ALM058HAGE
Catalog No:
HA458
EAN code:
3250613114589
Price:
933,16 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Isolating Load Switch. It is perfectly adapted to meet current requirements resulting from everyday electrical installation practice.
Current:
- Current carrying capacity of AC21 in category A: 630 A
- Rated operational current (AC23), category A: 630 A
- Current carrying capacity AC21 category B: 630 A
- Allowable current load AC22 category A : 630 A
- Allowable current load AC22 category B: 630 A
- Rated operational current (AC23), category B: 630 A
- Conventional short-circuit current: 45 kA
- Short-circuit current with gI-gG fuses: 50 kA
- Rated short-time withstand current Icw: 13 kA
- Rated short-time withstand current 1s: 13 kA
Power:
- Power supply below 440/500V 50Hz: 220 kW
- Power rating below 660V, 50 Hz.: 150 kW
- Active power below 380/415 V, 50 Hz: 220 kW
- Rated switching power for rated voltage 400V for AC1: 414 kW < li> Total power loss at rated current: 92.7 W
- Power loss per pole at rated current: 30.9 W
Technical data
-
Number of poles4
-
Rated current [A]630
-
power loss [W]92.7
-
Connection typeVice
-
Conventional short-circuit current [kA]45
-
Rated operational current [A]630
-
PKWIU27.12.22.0
-
Rated insulation voltage [V]1000
-
Level of securityIP00
-
Power loss per pole [W]30.9
-
Rated switching voltage [V]380/415
-
Rated surge voltage [V]8000
-
Conductor cross-section (wire) [mm²]2 x 300
Other technical data
-
Version as main switchYes
-
Version as safety switchYes
-
Version as reversing switchNo
-
Max. rated operation voltage Ue AC415 V
-
Rated permanent current Iu630 A
-
Rated permanent current at AC-21, 400 V630 A
-
Rated operation power at AC-23, 400 V225 kW
-
Conditioned rated short-circuit current Iq50 kA
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as change-over contact0
-
Motor drive integratedNo
-
Device constructionBuilt-in device fixed built-in technique
-
Suitable for front mounting 4-holeNo
-
Suitable for distribution board installationYes
-
Colour control elementBlack
-
InterlockableYes
-
Degree of protection (IP), front sideIP00
-
Version as maintenance-/service switchYes
-
Version as emergency stop installationNo
-
Number of switches1
-
Rated operating voltage380 ... 415 V
-
Rated permanent current at AC-23, 400 V630 A
-
Rated short-time withstand current lcw13 kA
-
Switching power at 400 V414 kW
-
Number of poles4
-
Number of auxiliary contacts as normally open contact0
-
Motor drive optionalNo
-
Voltage release optionalNo
-
Suitable for floor mountingYes
-
Suitable for front mounting centreNo
-
Suitable for intermediate mountingNo
-
Type of control elementLong turning handle
-
Type of electrical connection of main circuitCable clamp
-
Degree of protection (NEMA)Other
Manufacturer details
-
ManufacturerHAGER POLO Sp. z o. o.
-
Address43-100 Tychy Fabryczna 10
-
E-mail
-
Tax identification number6460015532
-
GLN5900009931532
Bulk packaging
| A kind of package | Karton | Paleta | |
| Quantity | 1 pcs. | 1 pcs. | 24 pcs. |
| Weight (kg) | 5,500 | 5,555 | 356,300 |
| Width (m) | 0,315 | 0,283 | 0,800 |
| Length (m) | 0,270 | 0,165 | 1,100 |
| Depth (m) | 0,160 | 0,304 | 1,200 |
