Flush-mounted bistable relay with a time switch for illuminated buttons with inrush relay 24V BIS-410-LED-24V
local index:
APC020FIFQ
Catalog No:
BIS-410-LED-24V
EAN code:
5908312590385
Price:
29,72 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Electronic bistable impulse relay, enables switching on lighting or other device from several different points by means of control buttons connected in parallel
Technical data
-
InstallationFlush-mounted
-
PKWIU27.12.23.0
-
Power [V]100÷265
Other technical data
-
FunctionElectronic switch
-
Width in number of modular spacings1
-
Type of control voltage 1AC
-
Voltage type (supply voltage)AC
-
Max. load fluorescent lamp1500 VA
-
Max. load fluorescent lamp (parallel compensated)1500 VA
-
Suitable for manual operationNo
-
Mounting methodFlush-mounted
-
Built-in depth25 mm
-
Frequency control voltage 150 ... 50 Hz
-
Max. incandescent lamp load3000 W
-
Max. load fluorescent lamp (Duo circuit)1500 VA
-
Max. switching current (cos phi = 0.6)16 A
Manufacturer details
-
ManufacturerF&F Filipowski S.K.
-
Address95-200 Pabianice Konstantynowska 79/81 Polska
-
E-mail
Bulk packaging
| A kind of package | Sztuka |
| Quantity | 1 pcs. |
| Weight (kg) | 0,056 |
| Width (m) | 0,031 |
| Length (m) | 0,095 |
| Depth (m) | 0,070 |
