Electromagnetic relay RM50-3011-85-1006 miniature, for printed circuit 2611653
local index:
APE490RELP
Catalog No:
2611653
Price:
199,60 €
gross / pkg.
(including VAT 23%)
2,00 € gross/pcs.
Delivery in 3h
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Electromagnetic relay, miniature, for printed circuit (sugar cube relays). Height 15.5mm. Output: 1P - one changeover contact - terminals: 11-12-14; AC1 - 10A / 240V; DC1 - 15 A / 24 V. Input / coil - terminals: A1 - A2, supply voltage Un - 6 V DC. Dimensions: 19 x 15.4 x 15.5mm. Direct mounting on the print, PCB. IP 64.
Technical data
-
Level of securityIP65
-
Height [mm]15.5
-
Pieces in the package100
Other technical data
-
Type of electric connectionPCB connection
-
Rated control supply voltage AC 60 Hz0 ... 0 V
-
Voltage type for actuatingDC
-
Drive, switching attitudeMono stable
-
Number of contacts as normally open contact0
-
Type of switch contactSingle contact
-
Degree of protection (IP)IP64
-
Height15.5 mm
-
Rated control supply voltage AC 50 Hz0 ... 0 V
-
Rated control supply voltage DC6 ... 6 V
-
Drive, polarizationPolarity free
-
Number of contacts as normally closed contact0
-
Number of contacts as change-over contact1
-
Complete with socketNo
-
Width15.4 mm
-
Depth19 mm
