EasyPact electronic circuit breaker CVS100F TMD 16A 3P 3D LV510330
local index:
ALP032SCHN
Catalog No:
LV510330
EAN code:
3606480220371
Manufacturer:
SCHNEIDER ELECTRIC
Height [mm]: 161
Price:
326,37 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
EasyPact electronic circuit breaker CVS100F TMD 16A 3P 3D
Technical data
-
Height [mm]161
-
PKWIU27.12.22.0
Other technical data
-
Rated permanent current Iu100 A
-
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz36 kA
-
Adjustment range undelayed short-circuit release190 ... 190 A
-
Type of electrical connection of main circuitScrew connection
-
Suitable for DIN rail (top hat rail) mountingNo
-
Number of auxiliary contacts as change-over contact0
-
Number of poles3
-
Type of control elementToggle
-
Motor drive integratedNo
-
Degree of protection (IP)IP40
-
Rated voltage440 ... 440 V
-
Overload release current setting0 ... 16 A
-
Integrated earth fault protectionNo
-
Device constructionBuilt-in device fixed built-in technique
-
DIN rail (top hat rail) mounting optionalNo
-
With switched-off indicatorYes
-
Position of connection for main current circuitFront side
-
Complete device with protection unitYes
-
Motor drive optionalNo
Manufacturer details
-
ManufacturerSchneider Electric Polska Sp. z o.o.
-
Address02-673 Warszawa ul. Konstruktorska 12
-
Phone number
-
Tax identification number5220011965
-
GLN5900009931556
